Precision Surface Grinding
Blanchard Grinding Services Built on Decades of Foundry Expertise
Flat, parallel, and finished to spec. C.L. Dews & Sons Foundry provides production-ready Blanchard grinding services for castings, forgings, plate stock, and fabricated components.
How Our Blanchard Grinding Process Works
What Happens When You Send Us a Grinding Job
1. Drawing and spec review. We start with your drawing or written specs: final thickness, flatness, parallelism, and any surface finish callout. If you are comparing large capacity Blanchard grinding services, tell us the part’s largest dimension up front. Our rotary table takes work up to 42 inches in diameter, and knowing the size early saves a round of back and forth.
2. Incoming check. When parts arrive at our Hattiesburg shop, we look at how much stock is available, whether the part is warped or bowed, and how it will seat on the magnetic chuck. A casting or flame-cut plate that rocks on the table needs a different setup than a flat blank.
3. The plan. We decide which face to grind first, how many parts fit on one table load, and which wheel and feed rate suit the material. Loading several parts together keeps thickness consistent from part to part.
4. Grinding and cleanup. We grind one face, turn the part over, and bring the opposite face into parallel, checking as we go. Parts are cleaned, inspected, and returned with the measured results.
How to Prepare Your Parts
- Note the finished thickness and how much material can come off each side.
- Remove bolted-on hardware, loose scale, and heavy burrs from the faces being ground.
- Flag heat-treated, thin, or nonmagnetic parts, since they change how we hold the work.
- Mark any face that must not be touched.
Questions Buyers Ask
What is the difference between a surface grinder and a Blanchard grinder? A Blanchard grinder is built for fast stock removal and flatness on large faces, while a reciprocating surface grinder suits smaller parts and finer finishes. Some parts are Blanchard ground to size first, then surface ground only where a finer finish is called out.
How is Blanchard grinding priced? We quote each job from your drawing, because cost depends on the part rather than a flat rate. The main drivers are how much stock comes off, how many parts fit on one table load, the tolerance required, and the material.
Will my part fit on your table? Our table holds work up to 42 inches across, so check your part’s diagonal, not just its length. A 30 by 30 inch plate, for example, measures about 42.4 inches corner to corner. If you are close to the limit, send the drawing and we will confirm.
Production-Ready Grinding for Castings, Plate, and Fabrications
Our Blanchard grinding services deliver the surface flatness and finish quality that downstream machining, assembly, and sealing operations demand. We pair rotary surface grinding capability with metalworking knowledge built since 1941 to take your parts from rough stock to precision-finished components.
42"
Max Table Diameter
±0.001"
Flatness Tolerance
100+
Years in Operation
What Is Blanchard Grinding?
Blanchard grinding, also called rotary surface grinding, uses a vertical spindle and rotating magnetic chuck to remove material quickly while producing a characteristic crosshatch surface pattern. It is one of the most efficient methods for achieving flatness on large or heavy workpieces.
Named after the Blanchard Machine Company that pioneered the process, this grinding method excels at stock removal and surface finishing simultaneously. The workpiece sits on a rotating magnetic table while a cup-shaped grinding wheel spins above it on a vertical axis. The opposing rotation of the table and wheel creates a distinctive crosshatch finish pattern that many engineers specify for gasket seating surfaces and mating faces.
Unlike reciprocating surface grinders that move a workpiece back and forth under a horizontal spindle, Blanchard grinders can process multiple parts per cycle by loading the entire table surface. This makes the process particularly cost-effective for production volumes. For a deeper technical overview of grinding processes and metallurgical considerations, the ASM International library provides extensive resources on material finishing standards.
Our Blanchard Grinding Capabilities
We maintain our Blanchard grinders to tight mechanical standards so your parts come off the table ready for the next operation, whether that is CNC machining, assembly, or direct installation.
Tolerances to ±0.001"
We hold flatness and parallelism tolerances as tight as one thousandth of an inch across the full workpiece surface, verified with precision measuring instruments.
Ferrous & Non-Ferrous Metals
Cast iron, carbon steel, stainless steel, tool steel, aluminum, and bronze. If it can be ground, we can process it on our Blanchard equipment.
Up to 42" Diameter
Our rotary table accommodates workpieces up to 42 inches in diameter and varying thicknesses, suitable for large castings, plates, and fabricated assemblies.
Fast Stock Removal
Blanchard grinding removes material significantly faster than reciprocating grinders, reducing cycle times and keeping your per-part costs down on production runs.
Applications & Industries Served
Blanchard grinding services from C.L. Dews & Sons Foundry support a wide range of industries that depend on flat, true surfaces. Our customers rely on us for both one-off jobs and recurring production schedules.
Mold base and die plate preparation
Casting cleanup and surface finishing
Hydraulic manifold face grinding
Structural steel plate flattening
Mining and aggregate equipment wear parts
Pump and valve body sealing surfaces
Fixture and tooling base plates
Press platen resurfacing
Many of these components arrive at our facility as raw castings or flame-cut shapes that need material removed and faces brought into tolerance. Because we also offer custom machining, we can combine Blanchard grinding with additional milling, drilling, or turning operations to deliver a fully finished part.
Why Choose Dews for Blanchard Grinding
We are not a grinding-only shop. We are a full-service foundry and machine shop that has been producing and finishing metal components since 1941. That integrated capability means fewer vendors, shorter lead times, and tighter control over your finished part quality.
Foundry-to-Finish
Under One Roof
When your part starts as a casting, keeping it in one facility from pour to grind eliminates shipping between vendors, reduces handling damage risk, and compresses your delivery schedule. Our team manages the full workflow so your project stays on track.
Experienced Machinists
Blanchard grinding is straightforward in concept but demands experienced operators to set up jobs correctly, choose the right wheel specifications, and dial in feed rates for each material. Our machinists bring years of hands-on grinding experience to every job.
Quality You Can Measure
Every ground surface is inspected for flatness and finish quality before it leaves our shop. We document our results so you have the data you need for your own quality records. If your job requires specific surface roughness values or geometric tolerances, we work to those specifications.
Ready to Get STARTED?
Send us your drawings or specifications and our team will provide a quote for Blanchard grinding services, CNC machining, or any combination of our capabilities.
